Zhejiang Jiacheng New Material Co., Ltd. is one of the leading manufacturers and suppliers of ed seal ring in China, also supports customized service. Welcome to wholesale bulk high quality ed seal ring in stock here from our factory. If you have any enquiry about quotation and free sample, please feel free to email us.

_01

Size standard: DIN 3869

Material: green FKM, black NBR, as you need

Hardness: 85 Shore, as you need

ED seal ring is standard elastomeric (soft) seals for threaded connectors. It’s special shape enables them to be used in high-pressure applications, compensates for manufacturing tolerances and provides reliable sealing action. ED seal ring is widely used in pneumatic hydraulic joints such as pipe joints, hydraulic plugs and transition joints

Advantages

- Small mechanical deformation of the section

- No relative movement during pressure cycling

- Keep excellent sealing performance for a long time

- Working pressure can reach 60Mpa

Common dimension table

No.	IMPERIAL	THREAD	SIZE
No.	IMPERIAL	THREAD	SIZE
8	——	M8*1.0	6.59.91.0
10	G1/8A	M10*1.0	8.4x11.9x1.0
12	——	M12*1.5	9.8x14.4x1.5
14	G1/4A	M14*1.5	11.6x16.5x1.5
16	——	M16*1.5	13.8x18.9x1.5
17	G3/8A	G3/8"*19	14.7x18.9x1.5
18	——	M18*1.5	15.7x20.9x1.5
20	——	M20*1.5	17.8x22.9x1.5
21	G1/2A	G1/2"*14	18.5x23.9x1.5
22	——	M22*1.5	19.6x24.3x1.5
24	G 5/8A	M24*1.5	21.826.91.5
26	G3/4A	M26*1.5	23.9x29.2x1.5
27	G3/4A	M27*2.0	23.9x29.2x1.5
33	G1A	M33*2.0	29.7x35.7x2.0
42	G1-1/4	M42*2.0	38.8x45.8x2.0
48	G1-1/2	M48*2.0	44.7x50.7x2.0
60	G2	M60*2.0	56.566.54.0

_02

_03

_04

_05

_06

_07

_08
